Chemical Composition, Mechanical & Physical Properties of Nickel Alloy 200/201

Chemical Composition of Nickel 200/201

• Weight % (all values are maximum unless a range is otherwise indicated)

Mechanical Properties of Nickel 200/201

Physical Properties of Nickel 200/201

What are the Properties of Nickel 200/201?

• Heat-Resistant Applications. Nickel-base alloys are used in many applications where they are subjected to harsh environments at high temperatures. Nickel-chromium alloys or alloys that contain more than about 15% Cr are used to provide both oxidation and carburization resistance at temperatures exceeding 760°C. Nickel 200 is normally limited to service at temperatures below 600ºF (315ºC), since at higher temperatures it can suffer from graphitization which can severely compromise properties. At higher temperatures Nickel 201 should be utilized. Both grades are approved under ASME Boiler and Pressure Vessel Code Section VIII, Division 1. Nickel 200 is approved for service up to 600ºF (315ºC), while Nickel 201 plate is approved up to 1250ºF (677ºC).
• Corrosion Resistance:- Nickel-base alloys offer excellent corrosion resistance to a wide range of corrosive media. However, as with all types of corrosion, many factors influence the rate of attack. The corrosive media itself is the most important factor governing corrosion of a particular metal.
• Nickel 200 (UNS N02200) and 201 (UNS N02201) are dual-certifiable wrought nickel materials. They differ only in the maximum carbon levels present—0.15% for Nickel 200 and 0.02% for Nickel 201.
• Nickel 200 and 201 are ferromagnetic and exhibit highly ductile mechanical properties across a wide temperature range. Both grades are easily welded and processed by standard shop fabrication practices.
• Alloy 200/201 is extremely resistance to caustic alkalies up to and including the molten state. The extra-low carbon content of Alloy 200/201 gives virtual immunity to intergranular attack above about 315°C. The presence of chlorates must be kept to a minimum, as they accelerate the rate of attack.
• Commercially pure wrought Nickel with good mechanical properties over a wide range of temperature and excellent resistance to many corrosives, in particular hydroxides.
• Good resistance to corrosion in acids and alkalis and is most useful under reducing conditions. In acid, alkaline and neutral salt solutions the material shows good resistance, but in oxidizing salt solutions severe attack will occur.
• Resistant to all dry gases at room temperature and in dry chlorine and hydrogen chloride may be used in temperatures up to 550C.
• Resistance to mineral acids varies according to temperature and concentration and whether the solution is aerated or not.
• Corrosion resistance is better in de-aerated acid.

What are the Applications of Nickel 200/201 Alloy?

Nickel 200/201 is used in viscose rayon and polymer production, food processing, reactors, tubes, aerospace engineering, military and other applications.

• Chemical processing and storage
• Food processing equipment
• Salt production
• Caustic handling equipment
• Synthetic fiber production
• Manufacturing equipment, reactors and vessels where sodium hydroxide and fluorine is used
• Aerospace and defense

Testing & Inspection of Nickel Alloy 200/201 Products

Testing (Destructive, Non Destructive)

Inspection

• Our internal inspection reports would be provided for all the goods before shipment.
• Buyers or their associates are most welcome to visit us for personal inspect
• We regularly have inspections ongoing at our premises from internationally acclaimed Inspection Agencies such as TUV, BVIS, SGS, Llyods, DNV etc.

Prices for Nickel Alloy 200/201 Materials

Prices for Nickel Alloy 200/201 materials are directly co related to prices of the raw materials such as iron ore, metal scrap, chromium, nickel and various other alloying elements. The production cost of heat resistant stainless steel and nickel alloy plates is high as they contain high amount of nickel and chromium. Meanwhile, mild steel material is among the lowest cost steel available, followed by carbon steel, 400 series stainless steels, aluminium, alloy steel, and 300 series stainless steel. Special alloys such as titanium, Inconel, Monel and Hastelloy cost very high as the nickel, chromium and moly content is very high.

For special and discounted prices for various types of Nickel 200/201 products, please feel free to contact us through email, phone or whatsapp.

We are also regularly publishing our price list for various steel products on our blog.

Documents Provided at the time of Domestic Sales or Export of Nickel Alloy 200/201 Products

Price Terms for Nickel Alloy 200/201 Materials

We can offer any of the following price basis depending on your requirement:

• Ex-works
• FOR Site in India
• FOB Nhava Sheva
• CFR, CIF, CPT your destination port
• Door to Door Delivery Duty Paid as well as Duty Unpaid

Delivery Time of Nickel Alloy 200/201 Materials

• If the items are available in stock, we take 2 days from the date of receipt of advance payment to clear the shipment and send it to port.
• And in-case the items are not availabe in stock, the time taken for manufacturing depends on the size, quantity and grade.
• However we can claim the fact that we can compete with anyone in India on Delivery time and most of the time our production time is the least.
• We have tied up with strong logistic partners in India which can undertake any type of shipping activities and make sure that there is no delay in shipment.

Marking & Packing of Nickel Alloy 200/201 Materials

• All our products will have complete marking details which are co-related to the test certificates we supply.
• In case of orders for cut piece of Pipes, Sheets or Round Bars, the marking is transferred from the product from which it is cut. In such cases we provide Letter confirming the marking transfer and picture of the product from which it is cut.
• All goods are packed in wooden cases or pallets.
